The Self-Aligning QuickFit Gearbox Coupler allows the gearbox and motor to be installed directly onto the shaft in any radial position and alleviates installation problems due to uneven deck thickness. This is helpful when installing a windlass onto a deck with any camber to the deck surface. QuickFit connection simplifies installation.
Specifications:
- Version Capstan
- Motor Wattage 1200W
- Warranty 5 years
- Vessel Length 38-48 ft (12-15m)
- Max Load 2200 lb (1000 kg)
- Work Load 550 lb (250 kg)
- Chain Sizes 5/16BBB or HT, 3/8BBB or HT
- Amps Work Load 120
- Max Line Speed 50 ft/min (15 m/min)
- Rope Sizes 1/2, 9/16, 5/8 in.
- Approximate Ship Weight (lbs) 64
- Standard Equipment: Footswitch,Rope Chain Management System ,Clutch Handle
